Warranty – Limited 3-year
GIGABYTE SSD 120GB
– Total Capacity: 120GB
Read speed – up to 500 MB/s
-Write speed – up to 380 MB/s
– Random Read IOPS – Up to 50k
– Random Write IOPS – Up to 60k
GIGABYTE SSD 240GB
– Total Capacity: 240GB
– Read speed : up to 500 MB/s
– Write speed : up to 420 MB/s
– Random Read IOPS – up to 50k
Random Write IOPS – up to 75k
GIGABYTE SSD 480GB
– Total Capacity: 480GB
– Read speed : up to 550 MB/s
– Write speed : up to 480 MB/s
– Random Read IOPS – up to 75k
– Random Write IOPS – up to 70k
GIGABYTE SSD 1TB
– Total Capacity: 1TB
– Read speed : up to 550 MB/s
– Write speed : up to 500 MB/s
– Random Read IOPS – up to 75k
– Random Write IOPS – up to 85k
Specification:
– Form Factor: 2.5-inch internal SSD
– Interface: SATA 6.0Gb/s
– Interface – SATA 6.0Gb/s
– TRIM & S.M.A.R.T supported- NAND – NAND Flash
– External DDR Cache – N/A
– Dimension – 69.85 x 7 x 100 mm
– Mean time between failure (MTBF) – 2M hours
– Power Consumption (Active) – Average: R : 2240mW; W : 2610mW
– Power Consumption (Idle) – 170mW
– Temperature (Operating) – 0°C to 70°C
– Temperature (Storage) – -40°C to 85°C
Note
* Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
* Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark v.5.1.2 and I0meter 1.1.0.
* Speeds based on internal testing. Actual performance may vary.
* TBW (Terabyte Written):Terabytes Written" is the total amount of data that can be written into an SSD before it is likely to fail.
* 1GB = 1 billion bytes. Actual usable capacity may vary.
